Features

Serial Interface

• One DB9 interface that supports RS232
• One terminal block interface that supports 2-wire RS485 and 4-wire RS422/RS485 standards
• Asynchronous serial data rates up to 921600bps
• Data modes include VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair, Modbus converter server / client and Serial Telnet modes

Ethernet Interface

• 1-port 10/100BASE-TX RJ45  with auto MDI/MDI-X function

Management

• IPv4 and IPv6 dual stack management
• Remote Management Interfaces
• IP NTP (Network Time Protocol) and DNS management
• Standard TCP/IP interface and versatile operation modes
• Software Protocol supports ARP, ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client
• Serial Operation mode selected via management interface
• Pair Connection mode for connecting two serial devices over a network
• Allows a maximum of 4 hosts to be accessed as TCP client mode
• Firmware upgrade via HTTP protocol
• Accessible IP security control to prevent illegal users
• Event notification
• DHCP client for IP address assignment
• PLANET Smart Discovery utility automatically finds the client devices on the network

Industrial Case and Installation

• IP30 metal case
• DIN-rail and wall-mount designs
• Redundant power design

• Supports 6000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
• Free fall, shock-proof and vibration-proof for industries
• Supports extensive LED indicators for network diagnosis
• Reset button for resetting to factory default
