Feature
Physical Port
- One 10/100/1000BASE-T with IEEE 802.3bt++ Gigabit RJ45 port
- 1 SFP port, supporting 100/100BASE-X transceiver dual mode
Power over Ethernet
- Complies with IEEE 802.3bt PoE++ Type-4 PSE
- Compatible with IEEE 802.3at/af PoE+ standard
- 1 IEEE 802.3 bt/at/af device powered
- Supports PoE Power up to 95 watts for PoE port
- Provides DC 55V power over RJ45 Ethernet cable to PD with Ethernet port
- Auto detects IEEE 802.3bt/at/af equipment and protects devices from being damaged by incorrect installation
- Remote power feeding up to 100m
- Auto detects powered device (PD)
Layer 2 Features
- Supports auto-negotiation and 10/100Mbps half / full duplex and 1000Mbps full duplex mode on RJ45 port
- Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
Hardware
- LED Indicators
- System: Power 1, Power 2, Alarm and PoE usage
- Fiber port: LNK/ACT
- 10/100/1000BASE-T port: LNK/ACT, PoE-in-use
- DIP switch 1: LFPP (Link Fault Passthrough PoE Control) On/Off
- DIP switch 2: PoE+ plus Legacy (PoH) or Force mode selection
Industrial Case and Installation
- IP30 metal case
- DIN-rail, wall-mount or side wall-mount design for redundant power design
- 12 ~ 56V DC redundant power with reverse polarity protection and connective removable terminal block for master and slave power
- Supports 6000 VDC Ethernet ESD protection
- -40 to 75 degrees C operating temperature
