Hardware

• 5 10/100/1000BASE-T RJ45 ports
• 1 undefined Ethernet port (LAN/WAN)
• Dual-WAN function
• 1 USB 3.0 port for system configuration backup and firmware upgrade
• Reset button

Industrial Case and Installation

• IP30 metal case
• Solid DIN-rail, wall-mount  or side wall-mount design
• Supports 6KV DC Ethernet ESD protection
• Fault alarm for power input failed
• DC redundant power with reverse polarity protection
• -40 to 75 degrees C operating temperature

IP Routing Feature

• Static Route
• Dynamic Route (RIPv1/v2)

Firewall Security

• Stateful Packet Inspection (SPI) firewall
• Blocks DoS/DDoS attack
• Web filtering
• MAC/IP filtering
• Blocks SYN/ICMP flooding

VPN Features

• IPSec (Host to Host)/GRE/PPTP server/L2TP/SSL(Open VPN)
• Max. Connection Tunnel Entries: 60 VPN tunnels,
• Encryption methods: DES, 3DES, AES, AES-128/192/256
• Authentication methods: MD5, SHA-1, SHA-256, SHA-384, SHA-512

Networking

• Outbound load balancing
• Failover for dual-WAN
• PPPoE/Static IP/DHCP client for WAN
• Protocols: TCP/IP, UDP, ARP, IPv4, IPv6
• Port forwarding
• QoS
• DMZ
• VLAN
• IGMP Proxy
• SNMP (v1/v2C/v3)
• DHCP server/NTP client
• MAC address clone
• DDNS: PLANET DDNS, PLANET Easy DDNS, DynDNS or No-IP
• Cybersecurity

Others

• Setup wizard
• Dashboard for real-time system overview
• Supported access by HTTP or HTTPS
• Auto reboot
• Configuration backup and restoration via remote/USB port
• Firmware upgrade via remote/USB port
• Event message logging to remote syslog server
• PLANET Smart Discovery utility/UNI-NMS supported
