Physical Port

• 8-Port 10/100/1000BASE-T Gigabit RJ45 copper with 4-Port IEEE 802.3at PoE+ Injector (Port-1 to Port-4)

Power over Ethernet

• Complies with IEEE 802.3at Power over Ethernet Plus, end-span PSE
• Backward compliant with IEEE 802.3af Power over Ethernet end-span PSE
• Up to 4 ports of IEEE 802.3at devices powered
• Supports PoE Power up to 30.8 watts for each PoE port
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 250 meters (in extend mode)

Layer 2 Features

• High performance Store and Forward architecture
• IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
• 9K jumbo frame supports in 1000Mbps duplex mode
• Automatic address learning and address aging

Industrial Case and Installation

• Compact size; fixed wall mounting, magnetic wall mounting or DIN-rail mounting
• IP30 metal chassis
• Supports -20 to 60 degrees C operating temperature
• LED indicators for real-time PoE usage
• 48V~56V DC input range
